Product Description:
40 W DC/DC 8-36 VDC input; -12 V, 12 V, 5 V, 3.3 V, 5 VSB
- High efficiency up to 90%
- Over voltage protection
- Over Current Protection
- Input power protection
- Short circuit protection
- Low quiescent current
- Low EMI & RFI
- RoHS compliant
- Remote on/off
- AT or ATX mode
- Non-isolated type
| Input |
8 VDC to 36 VDC |
| Output |
5 V@8 A, -12 V @0.5 A,
12 V@2.5 A, 3.3 V@7 A& 5 VSB@1 A
Max. total output: 40 W |
| Performance
Characteristics |
Line regulation: <20
mV*
Load regulation: <150 mV
Efficiency: up to 90%
Quiescent current: <2 mA**
* Measure on 5 V ouput
** The LEDs and the 5 VSB are disabled. |
| Remote
on/off (jumper select) |
signal PS_ON control
power on/off
Active high or active low |
| Operation
Temperature |
-40ºC ~ 85ºC |
| Dimensions |
3.775" X 3.55" |
|
