Device Type |
UPS - external |
Battery
Enclosure Type |
Internal |
Width |
12 in |
Depth |
7 in |
Height |
4 in |
Enclosure Color |
Black |
Power Device |
UPS Technology |
Line interactive |
Input Voltage |
AC 120 V |
Input Voltage
Range |
AC 83 - 147 V |
Frequency
Required |
60 Hz |
Input
Connector(s) |
1 x power NEMA 5-15 |
Output Voltage |
AC 120 V ( 60 Hz ) |
Output
connector(s) |
12 x power NEMA 5-15 |
Power Output
Connectors Details |
6 x power NEMA 5-15 ( surge )
6 x power NEMA 5-15 ( UPS and surge ) |
Power Provided |
480 Watt / 900 VA |
Dataline Surge
Protection |
Network/phone line |
Output Waveform |
Sinewave |
Surge Suppression |
Standard |
Surge Energy
Rating |
252 Joules |
Battery |
Technology |
Lead acid |
Voltage Provided |
12 V |
Run Time (Up To) |
3 min at full load |
Networking |
Remote
Management Interface |
USB |
Expansion / Connectivity |
Interfaces |
1 x management - USB - 4 pin USB
Type B |
Miscellaneous |
Cables Included |
1 x power cable - 6 ft
1 x phone cable |
Equipment
Protection Value |
100000 US Dollars |
Features |
Audible alarm, Automatic Voltage
Regulation (AVR), LED indicators |
Compliant
Standards |
NOM, UL 1778, FCC Part 68, CSA C22.2 |
Software / System Requirements |
Software Included |
TrippLite PowerAlert |
Manufacturer Warranty |
Service &
Support |
2 years warranty |
Service &
Support Details |
Limited warranty - 2 years |
Environmental Parameters |
Min Operating
Temperature |
32 °F |
Max Operating
Temperature |
104 °F |
Humidity Range
Operating |
0 - 95% |
Dimensions & Weight (Shipping) |
Shipping Width |
14.5 in |
Shipping Depth |
9.8 in |
Shipping Height |
5.5 in |
