| Mechanical |
| Input Method |
Finger, Stylus
|
| Available
Sizes |
6.5" to 19" |
| Electrical |
| Wire Type |
4-wire, 5-wire |
Position Accuracy
|
Less than 1.5% |
Isolation
|
≥ 20M ohm |
Resolution
|
2048 x 2048 dpi based on
controller resolution |
Activation
Force
|
Less than 100g |
Controller Interface
|
Serial(RS-232) / USB1.1 |
Attached Cable
|
6' shielded cable with
USB-A connector for USB port
6' shielded cable with 9-pin D-sub connector |
| Panel resistance |
5 wire resistive model: 50
~ 200 ohm |
| Optical |
Light
Transmission
|
Anti-glare
type: 78% ~ 90% |
| Environmental
|
Temperature
|
Operating:
0°C to 50 °C
Storage: -20°C to 70 °C |
Relative Humidity
|
Operating: 20% to 90% RH
Storage: 20% to 90% RH |
Electrostatic Protection
|
30KV (Contact/ Air) |
| Durability |
Surface Hardness
|
3H and above per JIS K5400
|
| Life (Hitting)
|
More than 10 million hits |
Life (Drawing)
|
More than 300k alphabets |
| Operation
System Compatibility |
Windows Series
|
Windows XP/XP
Embedded / XP tablet edition,
Windows 2000, Windows ME, Windows 95/98,
Windows NT 4.0, Windows CE 2.12/3.0/.Net /5.0 |
Linux
|
Mandrake, Red-Hat |
| Mac/OS 9 &
X |
