Product Description:
Specifications
- Mfr Part Number: PDUMV20
- Features:
- Corded AC power distribution unit with 20 amp capacity and 20 AC receptacles
- Digital current meter display
- Sturdy 60 inch aluminum housing
- Included hardware allows for Zero-U configurations in rack enclosures
- Ideal for horizontal or vertical raceway style power distribution in office, workbench, industrial, network, and telecom applications
- Lighted power swith with locking transparent safety cover prevents accidental shutoff
- 20 amp electrical capacity
- 120V AC, 50/60Hz electrical compatibility
- 15 ft. power cord
- System overview: Vertical Corded PDU with Current Monitoring
- Voltage compatibility: 120 V
- Frequency compatibility: 50 / 60 Hz
- Output:
- Output volt amp capacity: 20 A
- Output watt capacity: 2400 W
- Output nominal voltage: 120 V
- Outlet quantity / type: 20x NEMA 5-15/20R
- Overload protection: 20 A
- Input:
- Maximum input amps: 20 A
- Input connection type: NEMA L5-20P with NEMA 5-20P plug adapter
- Input cord length: 15 feet
- Recommended electrical service: 20A 120V AC recommended with twist lock 20A wall receptacle
- LEDs Alarms & Switches:
- Front panel LEDs: Digital ammeter display
- Switches: Lighted on/off switch with integrated transparent saftey cover
- Material of construction: Aluminum
- Form factors supported: Vertical
- Switches: Lighted on/off switch with integrated transparent saftey cover
- Appearance: Silver housing with digital current meter display
- Certifications: UL60950-1 (USA); CAN/CSA C22.2 No. 60950-1-03 (Canada)
- Dimensions (WxDxH): 60 x 1.5 x 3 inch
- Weight: 5.2 lbs
- RoHS Compliant
|
