| General |
| Device Type |
UPS |
| Form Factor |
External |
| Battery Enclosure Type |
Plug-in module |
| Width |
11.3 in |
| Depth |
6 in |
| Height |
3.5 in |
| Weight |
11 lbs |
| Power Device |
| UPS Technology |
Off-line |
| Input Voltage |
AC 120 V |
| Frequency Required |
60 Hz |
| Input Connector(s) |
1 x power NEMA 5-15 |
| Output Voltage |
AC 115 V ± 5% ( 60 Hz ) |
| Output connector(s) |
8 x power NEMA 5-15 |
| Power Output Connectors Details |
4 x power NEMA 5-15 ( surge )
4 x power NEMA 5-15 ( UPS and surge ) |
| Power Provided |
550 VA |
| Dataline Surge Protection |
Phone line - RJ-11 |
| Output Waveform |
Sinewave |
| Surge Suppression |
Standard |
| Energy Rating |
1170 Joules |
| Battery |
| Type |
UPS battery |
| Expansion / Connectivity |
| Interfaces |
1 x USB - 4 pin USB Type A |
| Miscellaneous |
| Cables Included |
1 x phone cable - 6 ft
1 x USB cable
1 x phone cable |
| Equipment Protection Value |
100000 US Dollars |
| Features |
Audible alarm, LED display |
| Compliant Standards |
FCC Class B certified, CSA, TUV, UL 1778, FCC
Part 68, IC, DOC |
| Software / System Requirements |
| Software Included |
TrippLite PowerAlert |
| Manufacturer Warranty |
| Service & Support |
2 years warranty |
| Service & Support Details |
Limited warranty - 2 years |
