| Panel |
Cell Type / Glass Surface |
TFT LCD / Black Anti-Glare, low reflection coating |
| Aspect Ratio / Size |
4:3/ 20.1" viewable diagonal area |
| Active Area / Pixel Pitch |
408.0(H) x 306.0(V) mm / 0.255(H) x 0.255(V) mm |
| Native Resolution / Colors |
1600(H) x 1200(V) / 16.7 Million |
| Brightness / Contrast |
300 cd/m2 (typ) / 1000 :1 |
| Response Time |
^ 8 ms |
| Viewing Angle (typical) |
H. 160° (- 80° ~ + 80°) , V. 160°(- 80° ~ + 80°) |
| Light Source |
CCFL , Long life, 50,000 hrs (typ) |
| Input Sources |
PC System |
Signal |
Analog RGB (0.7/1.0 Vp.p, 75 ohms) |
| Sync |
Separate Sync, Composite Sync, Sync On Green |
| Frequency |
Fh: 30 - 82Khz , Fv: 50 -75Hz |
| Audio System |
2W Speaker x 2 |
| Input Terminals |
1 x VGA (15 Pin Female D-Sub), 1 x PC Audio (Stereo Headphone Jack), 1 x AC Outlet |
| Convenient Features |
Auto Calibration , Back Light Adjustment, Plug&Play (VESA DDC/CI, DDC 2B) |
| OSD Multi-Languages , Wall Mount Ready (VESA 100 x 100 mm) |
| Power |
Internal power supply with universal / Auto-Sensing, AC 90 to 260V, 50 / 60 Hz |
| Power Consumption |
Operation / Power Saving |
40 watt, < 5 watt (Support DPMS) |
| Operating Condition |
Temperature / Humidity |
0°C ~ 50°C (32°F ~ 122°F), 10% ~ 90% (no condensation) |
| Storage Condition |
Temperature / Humidity |
- 20°C ~ 60°C (- 4°F ~ 140°F), 10% ~ 90% (no condensation) |
| Certification |
|
FCC,CE |
| Dimensions |
Physical |
W x H x D = 530.0 x 420.0 x 73.0 mm |
| Carton |
W x H x D = TBD |
| Weight |
N.W. / G.W. |
7.7 Kgs / 8.7 Kgs |
| Container Loaded |
20ft / 40ft / 40ft HQ |
TBD (Sets , By pallet) |
