IBASE Technology
ITX, Socket478 for Core2Duo, GM45+ICH9M, w/ 82567 GbE LANx1 + 82574L GbE LANx1, VGA, COMx4, TPM1.2, PCIx1 & PCI-E(16x)x1+MiniPCI-Ex1 |
|
 INTERNATIONAL GROUND SHIPPING: For qualified orders, we will waive the Brokerage/Handling Fee for Custom Clearance and Documentation No other hidden fees will be collected from you when packages arrive. Guaranteed [ Detailed Explanation ] |
[ View Detail Product Info ]
|
Product Description:
Socket P CPU Intel® CoreTM2 Duo Up to 2.53GHz or above CPU Front Side Bus ( FSB ) 667 / 800 / 1066MHz Chipset Intel® GM45 + ICH9M System Memory Two SO-DIMM DDR2 sockets, up to 4GB 667/800MHz DDR2 no ECC Video Integrated Chipset built-in GM45 / GMA 4500MHD VGA CRT, LVDS interface Shared memory, max. 1GB DVMT 5.0 daughter card support for 2nd CRT, RCA, s-video or HDTV, dual DVI LAN Dual Intel Gigabits Lan - Intel 82567LM Gigabit LAN - Intel 82574L PCI-E Gigabit LAN RJ-45 on board Audio ICH9M built-in audio + AC97 codec 7.1 ALC888 (Line out, Line, Mic jacks on board) LPC I/O W83627EHG+Fintek chipset supports 3xCOM(RS232), 1xCOM(RS232/422/485), Hardware Monitor Serial ATA Interface 4x SATA II ports, 3Gb/s PATA Interface (IDE) 1xIDE using (PCI-E ot PATA) 2 IDE devices featuring UDMA33/66/100 Serial Ports 1x RS-232/422/485 and 3x RS-232 ports USB (2.0) 4 USB 2.0 ports (4 on board, 4 via pin header) Digital I/O 4 in / 4 out BIOS Award BIOS, ACPI supported Watchdog Timer Generates system reset; 256 levels Hardware Monitoring Monitors system/CPU temperature and voltage status Expansion Slot 1x PCI-E (x16) 1x PCI32 (supports 2 masters) Edge Connectors PS/2 keyboard and mouse, COM1, VGA, two RJ45 /w USB stack, 6 connections Audio 7.1 Power Connector ATX, 20-pin Form Factor Mini-ITX Dimensions 170mm x 170mm (6.7" x 6.7") Rear Connectors  Environmental Factors Operating Temperature: 0°C~60°C (32°F~140°F) Storage Temperature: -20°C~80°C (-4°F~176°F) Relative Humidity: 10%~90% (non-condensing) |
